John Deere
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 34,716 lb |
|---|---|
| Fuel Capacity | 79.0 gal |
| Front Axle/Diff Fluid Capacity | 5.9 gal |
| Rear Axle/Diff Fluid Capacity | 4.5 gal |
| Rated Bucket Capacity | 3.51 yd³ |
Engine
| Engine Model | PowerTech PVX 6068 |
|---|---|
| Displacement | 415 in³ |
| Net Power | 186.0 hp |
| Engine Make | John Deere |
| Make | Deere |
| Torque Rise | 64.0 % |
| Torque | 609 lb-ft |
| Alternator | 130 A |
| System Voltage | 24 V |
| Rated Speed | 1,800 rpm |
| Transmission Type | Powershift |
| Emission level | Tier 4 |
| Engine Output-Net | 186.5 hp |
| Pump | Piston |
Weights
| Operating Weight | 34,134 lb |
|---|
Dimensions
| Height - Top of Cab | 156 in |
|---|---|
| Wheelbase | 122 in |
| Width Over Tires | 106 in |
| Reach at Max Lift and Dump | 62 in |
| Length with Bucket on Ground | 306 in |
| Hinge Pin - Max Height | 151 in |
| Turning Circle | 512 in |
Transmission
| Pump Flow | 59.0 gal/min |
|---|---|
| System Pressure | 248 psi |
Fluid Capacities
| Hydraulic Tank | 27.8 gal |
|---|---|
| Transmission | 7.2 gal |
| Heaped Capacity | 3.60 yd³ |
Bucket
| Bucket Capacity - Smallest | 3.60 yd³ |
|---|---|
| Dump Clearance at Max Raise | 114 in |
| Breakout Force | 28,266 lb |
| Largest bucket capacity | 5.40 yd³ |
Driveline
| Ride control system | Optional |
|---|---|
| Parking Brake Type | Wet Multi Disc - Driveline |
| Service Brake - Location | Axle Inboard |
| Service Brake Actuation | Hydraulic |
| Service Brake Type | Wet Disc |
| Tire size - Standard | 20.5 R25 |
| Differential lock | Front- Locking Rear- Open |
