John Deere
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 5,385 lb |
|---|---|
| Max Speed | 7.3 mph |
| Fuel Capacity | 14.4 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Operating Speed | 7.3 mph |
Engine
| Engine Model | Series 220 |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 3,000 rpm |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 15.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,650 psi |
| Pump Type | Open-center |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 76 in |
| Wheelbase | 43 in |
| Reach at Max Lift and Dump | 280 in |
| Length with Bucket | 127 in |
| Clearance at Max Lift and Dump | 91 in |
| Turning Radius from Center - inc bucket | 45 in |
| Turning Radius from Center - machine rear | 45 in |
| Length w/o Bucket | 102 in |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Operating Load Rating | 1,670 lb |
| Tipping Angle | 2,000 ° |
| Breakout Force | 3,712 psi |
Comparable machines
Other skid steer loaders in a similar weight class.
