John Deere
Terex
HML42
Excavator
32 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 39,935 lb |
|---|---|
| Fuel Capacity | 70.0 gal |
| Hydraulic Pump Flow Capacity | 84.0 gal/min |
| Hydraulic System Fluid Capacity | 80.0 gal |
| Hydraulic System Relief Valve Pressure | 2,500 psi |
| Engine Oil Capacity | 25.0 gal |
| Cooling System Fluid Capacity | 42.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 8.0 gal |
| Alternator Supplied Amperage | 42 A |
Engine
| Engine Model | 6-466T |
|---|---|
| Displacement | 466 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 134.0 hp |
| Net Power | 125.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 450 lb-ft |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 120 in |
| Tail Swing Radius | 108 in |
| Width to Outside of Tracks | 114 in |
| Removal Counterweight Clearance | 39 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 90 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 1.8 mph |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 252 in |
|---|---|
| Max Reach Along Ground | 360 in |
| Max Loading Height | 180 in |
| Max Cutting Height | 264 in |
| Shipping Length of Unit | 360 in |
| Shipping Height of Unit | 131 in |
Bucket
| Reference Bucket Capacity | 0.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.40 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 8 rpm |
|---|
