John Deere
Caterpillar
933C LGP
Crawler Loader
38 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 26,791 lb |
|---|---|
| Max Speed | 5.5 mph |
| Fuel Capacity | 60.0 gal |
| Hydraulic System Fluid Capacity | 13.5 gal |
Engine
| Engine Model | 6068T |
|---|---|
| Displacement | 414 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 115.0 hp |
| Number of Cylinders | 6 |
Hydraulic System
| Pump Flow Capacity | 25.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,200 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 121 in |
| Length with Bucket on Ground | 189 in |
Undercarriage
| Length of Track on Ground | 102 in |
|---|---|
| Track Gauge | 70 in |
| Ground Pressure | 6 psi |
| Number of Track Rollers per Side | 7 |
| Ground Contact Area | 4,514 in³ |
| Number of Shoes per Side | 42 |
