434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
64 data points
Operating Specifications
| Operating Weight 4wd | 26,000 lb |
|---|---|
| Operating Weight 2wd | 23,000 lb |
| Fuel Capacity | 69.0 gal |
| Hydraulic System Fluid Capacity | 40.0 gal |
| Cooling System Fluid Capacity | 6.9 gal |
| Tire Size Front - 2wd / 4wd | 14.5/75-16 10PR/15-19.5 8PR |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 5.3 gal |
| Alternator Supplied Amperage | 90 A |
| Turning Radius | 180 in |
| Transmission Fluid Capacity | 4.0 gal |
| Rear Axle Fluid Capacity | 4.3 gal |
| Front Axle Fluid Capacity | 2.4 gal |
Engine
| Engine Model | 6068T |
|---|---|
| Displacement | 414 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 123.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,300 rpm |
| Net Max Torque | 395 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 52.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
| Pump Type | Axial-piston |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 100 in |
| Transport Width | 96 in |
| Transport Length | 322 in |
| Height to Top of Suspended Cab | 118 in |
Transmission
| Max Speed | 24.7 mph |
|---|---|
| Max Speed - Reverse | 17.0 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
| Transmission Type | Powershift |
Tires & Wheels
| Rear Tires Size | 21L-28 14 PR |
|---|
General Specifications
| Operating Weight lbs (kg) | 23,000(10,450) — Starting 2007 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 17.8 (5.4) — Starting 2009 Model Year |
| Lift Capacity lbs (kgs) | 8,693 (3,943) — Starting 2007 Model Year |
| Loading Height ft (m) | 14.4 (4.38) — Starting 2007 Model Year |
| 4th Gear Fwd mph (kmh) | 24.6 (39.5) — Starting 2007 Model Year |
| Backhoe Loading Height ft. (m) | 14.4 (4.4) — Starting 2009 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 24.6 (39.5) — Starting 2009 Model Year |
| Breakout Force lbs (kgs) | 15,540 (7,048) — Starting 2007 Model Year |
| Digging Depth ft (m) | 17.8 (5.4) — Starting 2007 Model Year |
| Loader SAE HP (kw) | 123 (91) — Starting 2009 Model Year |
| Loader Lift Capacity lbs. (kg) | 8,693 (3,943) — Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 15,540 (7,048) — Starting 2009 Model Year |
| SAE Net hp (kW) | 123 (91) — Starting 2007 Model Year |
| SAE HP (KW) | 123 (91) — Starting 2010 Model Year |
| Weight lbs (kg) | 23,000 (10,450) — Starting 2010 Model Year |
Backhoe
| Dig Depth | 215 in |
|---|---|
| Reach From Swivel | 270 in |
| Dig Depth - Extended | 269 in |
| Load Height - Extended | 204 in |
| Bucket Dig Force | 17,000 lb |
| Reach From Swivel - Extended | 323 in |
| Load Height | 172 in |
Loader
| Bucket Capacity | 1.70 yd³ |
|---|---|
| Lift Capacity | 8,693 lb |
| Clearance at Max Dump Height | 115 in |
| Bucket Breakout Force | 15,540 lb |
| Bucket Width | 97 in |
| Reach at Max Dump Height | 28 in |
| Dig Depth | 4 in |
