John Deere
Case
721E
Wheel Loader
49 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 51,057 lb |
|---|---|
| Fuel Capacity | 100.0 gal |
| Hydraulic System Fluid Capacity | 31.0 gal |
| Operating Voltage | 24 V |
| Turning Radius | 217 in |
| Engine Oil Fluid Capacity | 6.7 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 80 A |
| Cooling System Fluid Capacity | 8.2 gal |
| Transmission Fluid Capacity | 7.2 gal |
Engine
| Engine Model | 6081H |
|---|---|
| Displacement | 496 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 250.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged charge air cooled |
| Torque Measured @ | 1,300 rpm |
| Torque Rise | 49.0 % |
Hydraulic System
| Raise Time | 6.0 s |
|---|---|
| Lower Time | 30.0 s |
| Dump Time | 1.2 s |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 134 in |
| Wheelbase | 126 in |
| Reach at Max Lift and Dump | 46 in |
| Length with Bucket on Ground | 330 in |
| Hinge Pin - Max Height | 163 in |
Transmission
| Max Speed - Forward | 22.0 mph |
|---|---|
| Max Speed - Reverse | 55.5 mph |
| Transmission Type | Countershaft-Type Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 4.80 yd³ |
|---|---|
| Bucket Capacity - struck | 4.20 yd³ |
| Dump Clearance at Max Raise | 114 in |
| Bucket Width | 120 in |
