570
Processor
18 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 51,260 lb |
|---|---|
| Max Speed | 2.4 mph |
| Fuel Capacity | 154.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
| Hydraulic System Fluid Capacity | 36.0 gal |
| Cooling System Fluid Capacity | 10.2 gal |
| Engine Oil Capacity | 7.4 gal |
Engine
| Engine Model | e 6081H Tier 2 |
|---|---|
| Displacement | 492 in³ |
| Gross Power | 241.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 907 lb-ft |
Dimensions
| Height - Top of Cab | 137 in |
|---|---|
| Overall Width | 126 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 8 |
| Shoe Size | 24 in |
| Ground Clearance | 30 in |
| Track Length | 174 in |
Boom
| Lift Capacity at Max Reach | 8,774 lb |
|---|---|
| Max Reach w/ Head | 333 in |
