John Deere
Mccormick
MTX185
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 27,553 lb |
|---|---|
| Fuel Capacity | 181.3 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 13,999 lb |
Engine
| Displacement | 9 in³ |
|---|---|
| Gross Power | 241.4 hp |
| Number of Cylinders | 6 |
| Aspiration | Dual turbochargers variable geometry turbo with fixed geometry turbo in series |
| Engine Make | John Deere |
Hydraulic System
| Pump Flow Capacity | 60.0 gal/min |
|---|---|
| Number of Remote Control Valves | 6 |
| Maximum system pressure | 2,958 psi |
Dimensions
| Wheelbase | 122 in |
|---|---|
| Front Tread Range | 88 in |
| Front Axle Clearance | 27 in |
Transmission
| Max Speed | 31.1 mph |
|---|---|
| Number of Forward Gears | 16 |
| Transmission Type | 16-speed PowerShift |
| Number of Reverse Gears | 5 |
