John Deere
8310R
- Operating Weight
- 27,218 lb
- Displacement
- 548 in³
- Power Measured @
- 1,900 rpm
- Gross Power
- 341.0 hp
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 27,218 lb |
|---|---|
| Fuel Capacity | 183.6 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 29,750 lb |
| 3 Point Hitch Type | 4N/3 |
| Cooling System Fluid Capacity | 10.9 gal |
| Engine Oil Capacity | 7.4 gal |
Engine
| Engine Model | PowerTech PSX |
|---|---|
| Displacement | 548 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 341.0 hp |
| Net Power | 310.0 hp |
| Number of Cylinders | 6 |
| PTO Power | 303.0 hp |
| Torque Rise | 37.0 % |
Hydraulic System
| Pump Flow Capacity | 35.0 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Relief Valve Pressure | 2,900 psi |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 96 in |
| Wheelbase | 120 in |
| Overall Length | 20 in |
| Tire Size | 420/85R34/480/80R50 |
Transmission
| Number of Forward Gears | 16 |
|---|---|
| Transmission Type | full power shift |
| Number of Reverse Gears | 4 |
Years of Manufacture
| Approximate First Year of Manufacture | 2,011 |
|---|---|
| Approximate Last Year of Manufacture | 2,013 |
