L110G
Wheel Loader
20 specifications
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 68,320 lb |
|---|---|
| Fuel Capacity | 135.0 gal |
| Tire Size | 29.5 R25 |
| Hydraulic System Fluid Capacity | 80.0 gal |
| Static Tipping Weight | 53,140 lb |
| Operating Voltage | 24 V |
| Turning Radius | 248 in |
| Engine Oil Fluid Capacity | 10.1 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 80 A |
| Front Axle/Diff Fluid Capacity | 14.6 gal |
| Rear Axle/Diff Fluid Capacity | 15.6 gal |
| Cooling System Fluid Capacity | 10.1 gal |
| Transmission Fluid Capacity | 7.4 gal |
Engine
| Engine Model | 6125H |
|---|---|
| Displacement | 766 in³ |
| Power Measured @ | 1,600 rpm |
| Net Power | 330.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged charge air cooled |
| Torque Measured @ | 900 rpm |
| Torque Rise | 60.0 % |
Hydraulic System
| Pump Flow Capacity | 169.0 gal/min |
|---|---|
| Raise Time | 5.9 s |
| Lower Time | 3.5 s |
| Dump Time | 1.9 s |
| Relief Valve Setting | 3,500 psi |
| Pump Type | Variable axial Piston |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 149 in |
| Wheelbase | 146 in |
| Reach at Max Lift and Dump | 60 in |
| Length with Bucket on Ground | 378 in |
| Hinge Pin - Max Height | 181 in |
Transmission
| Max Speed - Forward | 23.4 mph |
|---|---|
| Max Speed - Reverse | 17.0 mph |
| Transmission Type | Automatic Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 7.30 yd³ |
|---|---|
| Bucket Capacity - struck | 6.20 yd³ |
| Dump Clearance at Max Raise | 132 in |
| Breakout Force | 49,320 lb |
| Bucket Width | 137 in |
