John Deere
8820 Titan II
- Operating Weight w/o Attachment
- 25,485 lb
- Fuel Capacity
- 100.4 gal
- Displacement
- 466 in³
- Power
- 225.0 hp
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight w/o Attachment | 25,485 lb |
|---|---|
| Fuel Capacity | 100.4 gal |
Engine
| Engine Model | 6466AH-02 |
|---|---|
| Displacement | 466 in³ |
| Power Measured @ | 2,200 rpm |
| Number of Cylinders | 6 |
| Engine Make | John Deere |
| Power | 225.0 hp |
Dimensions
| Wheelbase | 150 in |
|---|---|
| Transport Width | 198 in |
| Transport Height | 150 in |
| Transport Length | 441 in |
| Unloader clearance | 146 in |
| Unloader reach | 143 in |
Tires & Wheels
| Rear Tires Size | 11.25 - 24 8-ply |
|---|---|
| Front Tires Size | 24.5 - 32 R1 12-ply |
Cleaning System
| Cleaning Fan Speed - High | 1,100 rpm |
|---|---|
| Cleaning Fan Speed - Low | 370 rpm |
| Cleaning Fan Description | 4 blade undershot Diameter: 505 mm Width 1632 mm |
Grain Handling
| Grain Tank Capacity | 2,001.5 gal |
|---|---|
| Unloading Speed | 1.9 bu/sec |
| Unloading Auger Length | 205 in |
| Unloading auger diameter | 12 in |
Threshing
| Rotor Diameter | 22 in |
|---|---|
| Rotor Speed - High | 1,230 rpm |
| Rotor Speed - Low | 700 rpm |
| Concave Area | 490 in³ |
| width | 73 in |
