John Deere
Kartar
4000
Combine
13 specifications
John Deere
9550
- Operating Weight w/o Attachment
- 24,758 lb
- Fuel Capacity
- 149.3 gal
- Displacement
- 494 in³
- Power
- 218.6 hp
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight w/o Attachment | 24,758 lb |
|---|---|
| Fuel Capacity | 149.3 gal |
| Number of Gears | 3 |
| Hydraulic System Fluid Capacity | 9.0 gal |
| Cooling System Fluid Capacity | 10.1 gal |
| Transmission Fluid Capacity | 2.6 gal |
Engine
| Engine Model | 6081H |
|---|---|
| Displacement | 494 in³ |
| Number of Cylinders | 6 |
| Engine Make | John Deere |
| Power | 218.6 hp |
| Power Boost Power | 254.8 hp |
Fluid Capacities
| Crankcase oil volume | 7.6 gal |
|---|
Electrical System
| Alternator | — |
|---|---|
| Voltage | 12 V |
Cleaning System
| Total Cleaning Area | 6,371 in³ |
|---|
Grain Handling
| Grain Tank Capacity | 2,008.0 gal |
|---|---|
| Unloading Speed | 2 bu/sec |
Separating
| Separator Type | Straw walkers |
|---|---|
| Width | 13 in |
