John Deere
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Fuel Capacity | 305.2 gal |
|---|
Engine
| Displacement | 763 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Number of Cylinders | 6 |
| Power | 374.2 hp |
| Power Boost Power | 407.7 hp |
Cleaning System
| Total Cleaning Area | 7,099 in³ |
|---|---|
| Cleaning Fan Speed - High | 1,200 rpm |
| Cleaning Fan Speed - Low | 500 rpm |
Feeding
| Conveyor Width | 55 in |
|---|---|
| Conveyor Length | 68 in |
| Conveyor Speed | 520 rpm |
Grain Handling
| Grain Tank Capacity | 2,801.1 gal |
|---|---|
| Unloading Speed | 3.4 bu/sec |
| Unloading Discharge Height | 173 in |
| Unloading Auger Length | 272 in |
Separating
| Separating Area | 2,387 in³ |
|---|---|
| Separator Type | Rotary |
| Discharge Grate Area | 558 in³ |
Threshing
| Rotor Diameter | 30 in |
|---|---|
| Rotor Length | 123 in |
| Rotor Speed - High | 1,000 rpm |
| Rotor Speed - Low | 210 rpm |
| Concave Area | 1,705 in³ |
