John Deere
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 5,483 lb |
|---|---|
| Max Speed | 6.5 mph |
| Fuel Capacity | 24.0 gal |
| Hydraulic System Fluid Capacity | 18.0 gal |
| Tire Size | 10-16.5steel-cap4PR/6.50-16lug treadsolid rubber |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 3.1 gal |
| Operating Speed | 6.5 mph |
Engine
| Engine Model | Y-112 4-cylinder 4-stroke |
|---|---|
| Displacement | 112 in³ |
| Gross Power | 37.0 hp |
| Aspiration | Hydrostatic |
Hydraulic System
| Pump Type | Pressure system with full-flow filter |
|---|
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 108 in |
| Wheelbase | 36 in |
| Width Over Tires | 49 in |
| Reach at Max Lift and Dump | 2 in |
| Length with Bucket | 119 in |
| Clearance at Max Lift and Dump | 84 in |
| Turning Radius from Center - machine rear | 4 in |
| Length w/o Bucket | 85 in |
Loader
| Bucket Capacity | 0.41 yd³ |
|---|---|
| Operating Load Rating | 1,349 lb |
| Tipping Angle | 2,701 ° |
