Jonyang

JY608

Excavator

Operating Weight
16,000 lb
Max Digging Depth
166 in
Net Power
80.5 hp
All excavators
Jonyang JY608 Excavator
1 / 5
Image 1 of 5
Image: alibaba.com

Specifications

19 data points

Operating Specifications

Operating Specifications specifications
Operating Weight16,000 lb
Hydraulic Pump Flow Capacity42.3 gal/min
Hydraulic System Relief Valve Pressure4,351 psi

Engine

Engine specifications
Engine ModelB3.3
Net Power80.5 hp

Dimensions

Dimensions specifications
Ground Clearance16 in
Height - Top of Cab98 in
Tail Swing Radius73 in
Width to Outside of Tracks88 in
Removal Counterweight Clearance32 in

Undercarriage

Undercarriage specifications
Ground Pressure5,512 psi
Track Gauge70 in
Max Travel Speed2.8 mph
Shoe Size18 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth166 in
Max Reach Along Ground256 in
Max Loading Height200 in
Max Cutting Height277 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed12 rpm
