New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 20,000 lb |
|---|---|
| Tire Size | 17.5-25 |
Engine
| Engine Model | TD226B-6 |
|---|---|
| Net Power | 123.4 hp |
Hydraulic System
| Raise Time | 6.0 s |
|---|---|
| Relief Valve Setting | 2,277 psi |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 127 in |
| Wheelbase | 109 in |
| Width Over Tires | 89 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 276 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Transmission Type | powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 2.30 yd³ |
|---|---|
| Dump Clearance at Max Raise | 128 in |
| Bucket Width | 97 in |
