Kawasaki
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 23,612 lb |
|---|---|
| Fuel Capacity | 55.5 gal |
| Tire Size | 17.5x25-12PR (L2) |
| Hydraulic System Fluid Capacity | 19.9 gal |
| Static Tipping Weight | 19,136 lb |
| Operating Voltage | 24 V |
| Turning Radius | 226 in |
| Engine Oil Fluid Capacity | 3.7 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 6.7 gal |
| Rear Axle/Diff Fluid Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 11.4 gal |
| Transmission Fluid Capacity | 6.7 gal |
Engine
| Engine Model | 6BTAA5.9 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 134.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged & intercooler |
| Torque Measured @ | 1,500 rpm |
Hydraulic System
| Pump Flow Capacity | 16.1 gal/min |
|---|---|
| Raise Time | 5.8 s |
| Lower Time | 2.9 s |
| Dump Time | 1.2 s |
| Relief Valve Setting | 3,000 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 115 in |
| Width Over Tires | 94 in |
| Reach at Max Lift and Dump | 43 in |
| Length with Bucket on Ground | 284 in |
| Hinge Pin - Max Height | 146 in |
Transmission
| Max Speed - Forward | 22.8 mph |
|---|---|
| Max Speed - Reverse | 22.8 mph |
| Transmission Type | full power shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.80 yd³ |
|---|---|
| Bucket Capacity - struck | 2.39 yd³ |
| Dump Clearance at Max Raise | 109 in |
| Breakout Force | 22,530 lb |
| Bucket Width | 97 in |
