Kawasaki

70ZV-2

Wheel Loader

Operating Weight
31,437 lb
Bucket Capacity - heaped
3.51 yd³
Gross Power
193.0 hp
Net Power
174.0 hp
All wheel loaders
Kawasaki 70ZV-2 Wheel Loader
1 / 5
Image 1 of 5
Image: veritread.com

Specifications

48 data points

Operating Specifications

Operating Specifications specifications
Operating Weight31,437 lb
Fuel Capacity71.4 gal
Tire Size20.5x25-12PR (L-2)
Hydraulic System Fluid Capacity45.0 gal
Static Tipping Weight25,022 lb
Operating Voltage12 V
Turning Radius239 in
Engine Oil Fluid Capacity6.4 gal
Rear Axle Oscillation24 °
Alternator Supplied Amperage70 A
Front Axle/Diff Fluid Capacity13.3 gal
Rear Axle/Diff Fluid Capacity13.8 gal
Cooling System Fluid Capacity8.0 gal
Transmission Fluid Capacity11.9 gal
Rated Bucket Capacity3.51 yd³

Engine

Engine specifications
Engine ModelQSB6.7
Displacement409 in³
Power Measured @2,200 rpm
Gross Power193.0 hp
Net Power174.0 hp
Number of Cylinders6
Aspirationturbocharged
Torque Measured @1,400 rpm
MakeCummins

Weights

Weights specifications
Operating Weight31,437 lb

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity18.2 gal/min
Raise Time5.9 s
Lower Time3.1 s
Dump Time1.2 s
Relief Valve Setting3,000 psi
Pump Typegear type

Dimensions

Dimensions specifications
Ground Clearance16 in
Height - Top of Cab132 in
Wheelbase121 in
Width Over Tires102 in
Reach at Max Lift and Dump43 in
Length with Bucket on Ground300 in
Hinge Pin - Max Height154 in

Transmission

Transmission specifications
Max Speed - Forward23.0 mph
Max Speed - Reverse23.3 mph
Transmission Typefull power shift
Number of Forward Gears4
Number of Reverse Gears4

Bucket

Bucket specifications
Bucket Capacity - heaped3.51 yd³
Bucket Capacity - struck3.00 yd³
Dump Clearance at Max Raise111 in
Breakout Force27,875 lb
Bucket Width106 in
