Kawasaki
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 33,270 lb |
|---|---|
| Fuel Capacity | 56.8 gal |
| Tire Size | 20.5-25-16PR (L-2) |
| Hydraulic System Fluid Capacity | 47.6 gal |
| Static Tipping Weight | 24,090 lb |
| Operating Voltage | 24 V |
| Turning Radius | 254 in |
| Engine Oil Fluid Capacity | 6.1 gal |
| Rear Axle Oscillation | 30 ° |
| Alternator Supplied Amperage | 65 A |
| Front Axle/Diff Fluid Capacity | 8.8 gal |
| Rear Axle/Diff Fluid Capacity | 8.8 gal |
| Cooling System Fluid Capacity | 13.3 gal |
| Transmission Fluid Capacity | 10.4 gal |
Engine
| Engine Model | 6CT-8.3-C |
|---|---|
| Displacement | 505 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 165.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 46.0 gal/min |
|---|---|
| Raise Time | 6.6 s |
| Lower Time | 3.2 s |
| Dump Time | 1.4 s |
| Relief Valve Setting | 2,775 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 131 in |
| Wheelbase | 118 in |
| Width Over Tires | 101 in |
| Reach at Max Lift and Dump | 44 in |
| Length with Bucket on Ground | 293 in |
| Hinge Pin - Max Height | 154 in |
Transmission
| Max Speed - Forward | 21.8 mph |
|---|---|
| Max Speed - Reverse | 22.7 mph |
| Transmission Type | full powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.70 yd³ |
|---|---|
| Bucket Capacity - struck | 3.30 yd³ |
| Dump Clearance at Max Raise | 108 in |
| Breakout Force | 34,840 lb |
| Bucket Width | 107 in |
