EX70
Excavator
39 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 17,284 lb |
|---|---|
| Fuel Capacity | 31.8 gal |
| Hydraulic Pump Flow Capacity | 34.9 gal/min |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Hydraulic System Relief Valve Pressure | 4,770 psi |
| Engine Oil Capacity | 3.0 gal |
| Cooling System Fluid Capacity | 2.3 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | AU-4LE2X |
|---|---|
| Displacement | 133 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 55.7 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged w/ Intercooler |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 148 lb-ft |
| Make | Isuzu |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 108 in |
| Tail Swing Radius | 52 in |
| Width to Outside of Tracks | 98 in |
| Removal Counterweight Clearance | 30 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 74 in |
| Max Travel Speed | 3.3 mph |
| Shoe Size | 24 in |
| Drawbar Pull | 16,100 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 181 in |
|---|---|
| Max Reach Along Ground | 264 in |
| Max Loading Height | 222 in |
| Max Vertical Wall Digging Depth | 152 in |
| Max Cutting Height | 304 in |
| Shipping Length of Unit | 252 in |
| Shipping Height of Unit | 118 in |
Bucket
| Reference Bucket Capacity | 0.41 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.60 yd³ |
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
