Kobelco

CK800

Crawler Crane

Max Lift Capacity
160,000 lb
Power Measured @
2,000 rpm
All crawler cranes
Kobelco CK800 Crawler Crane
1 / 5
Image 1 of 5
Image: empirecrane.com

Specifications

29 data points

Operating Specifications

Operating Specifications specifications
Operating Weight131,396 lb
Fuel Capacity74.0 gal
Hydraulic System Fluid Capacity66.0 gal

Engine

Engine specifications
Engine Model6D22C
Displacement677 in³
Power Measured @2,000 rpm
Gross Power174.4 hp
Number of Cylinders6
AspirationWater-cooled
Torque Measured @1,200 rpm
Max Torque498 lb-ft
Engine MakeMitsubishi
Stroke6 in
Bore5 in
Air cleanerTwo stage dry
Starter7.4 hp

Dimensions

Dimensions specifications
Ground Clearance16 in
Overall Width189 in
Gradeability40.0 %
Overall length of crawler238 in

Transmission

Transmission specifications
Max Speed0.8 mph

Undercarriage

Undercarriage specifications
Width of Shoes32 in
Number of Shoes per Side63
Number of Track Rollers per Side10

Boom

Boom specifications
Max Lift Capacity160,000 lb
Min Height @ Max Raise Angle480 in
Swing Speed3 rpm
Max Height @ Max Raise Angle - no jib2,160 in
Max Elevating Angle80 °
