Kobelco

SK140SRLC-3

Excavator

Operating Weight
31,100 lb
Max Digging Depth
1 in
Net Power
92.8 hp
All excavators
Kobelco SK140SRLC-3 Excavator
1 / 5
Image 1 of 5
Image: veritread.com

Specifications

38 data points

Operating Specifications

Operating Specifications specifications
Operating Weight31,100 lb
Fuel Capacity52.8 gal
Hydraulic Pump Flow Capacity33.5 gal/min
Hydraulic System Fluid Capacity22.6 gal
Engine Oil Capacity3.1 gal
Cooling System Fluid Capacity3.5 gal
Travel speed, high range3.5 mph
Travel speed, low range2.2 mph

Engine

Engine specifications
Engine ModelD04EG-74kW-01
Power Measured @2,000 rpm
Net Power92.8 hp
Max Torque3 lb-ft
Stroke5 in
Bore4 in

Hydraulic System

Hydraulic System specifications
Hydraulic System TypeTwo variable displacement pumps

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab113 in
Tail Swing Radius59 in
Gradeability70.0 %
Track Gauge79 in

Undercarriage

Undercarriage specifications
Ground Pressure5 psi
Shoe Size24 in
Number of Shoes per Side46
Drawbar Pull31,100 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Vertical Wall Digging Depth1 in
Max Digging Reach1 in
Max Digging Reach on Ground1 in
Max Dumping Clearance1 in
Min Dumping Clearance1 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed11 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth1 in
Max Vertical Wall Digging Depth1 in
Minimum swing radius0 in
Max Digging Reach1 in
Max Digging Reach on Ground1 in
Max Dumping Clearance1 in
Min Dumping Clearance88 in
Horizontal Digging Stroke - Ground1 in
