Kobelco
Komatsu
PC800-6
Excavator
28 specifications
1 / 5
Image 1 of 5
Specifications
45 data points
Operating Specifications
| Operating Weight | 214,730 lb |
|---|---|
| Fuel Capacity | 84.6 gal |
| Engine Oil Capacity | 5.4 gal |
| Cooling System Fluid Capacity | 5.1 gal |
| DEF tank capacity | 9.0 gal |
Engine
| Engine Model | Hino J05E UM |
|---|---|
| Displacement | 313 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 166.0 hp |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 348 lb-ft |
| Bore | 5 in |
| Stroke | 5 in |
| Engine Type | Direct injection water-cooled 4-cycle diesel engine with turbocharger intercooler(Complies with EU (NRMM) Stage IV EPA Tier IV Final. |
Dimensions
| Height - Top of Cab | 126 in |
|---|---|
| Tail Swing Radius | 115 in |
Undercarriage
| Ground Pressure | 12 psi |
|---|---|
| Track Gauge | 95 in |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 264 in |
|---|---|
| Max Vertical Wall Digging Depth | 240 in |
| Minimum swing radius | 140 in |
| Max Digging Reach | 391 in |
| Max Digging Reach on Ground | 374 in |
| Bucket Digging Force - SAE | 32,190 lb |
| Max Digging Height | 374 in |
| Bucket Digging Force - ISO | 35,300 lb |
| Max Dumping Clearance | 274 in |
| Min Dumping Clearance | 96 in |
| Arm Crowd Force - SAE | 24,500 lb |
Swing Mechanism
| Swing Speed | 6 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Vertical Wall Digging Depth | 256 in |
|---|---|
| Minimum swing radius | 137 in |
| Max Digging Reach | 398 in |
| Max Digging Reach on Ground | 401 in |
| Bucket Digging Force - SAE | 32,190 lb |
| Bucket Digging Force - ISO | 35,300 lb |
| Max Dumping Clearance | 265 in |
| Min Dumping Clearance | 74 in |
| Max. digging height | 385 in |
| Arm Digging Force - SAE | 22,100 lb |
Cylinders
| Bore (Boom) | 5 in |
|---|---|
| Bore (Bucket) | 5 in |
| Stroke (Bucket) | 43 in |
