Kobelco
Komatsu
PC800-6
Excavator
28 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 214,730 lb |
|---|---|
| Fuel Capacity | 84.6 gal |
| Engine Oil Capacity | 5.4 gal |
| Cooling System Fluid Capacity | 5.1 gal |
| DEF tank capacity | 9.0 gal |
Engine
| Engine Model | HINO J08E-VV |
|---|---|
| Displacement | 313 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 166.0 hp |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 359 lb-ft |
| Stroke | 5 in |
| Bore | 5 in |
| Engine Type | Direct injection water-cooled 4-cycle diesel engine with turbocharger intercooler(Complies with EU (NRMM) Stage IV EPA Tier IV Final. |
Dimensions
| Height - Top of Cab | 126 in |
|---|---|
| Tail Swing Radius | 115 in |
Undercarriage
| Ground Pressure | 12 psi |
|---|---|
| Track Gauge | 95 in |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
Swing Mechanism
| Swing Speed | 6 rpm |
|---|
Cylinders
| Bore (Boom) | 5 in |
|---|---|
| Bore (Bucket) | 5 in |
| Stroke (Bucket) | 43 in |
