Komatsu
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 15,476 lb |
|---|
Engine
| Engine Model | 6D95L-1 |
|---|---|
| Displacement | 299 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 81.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 108 in |
| Length of Track on Ground | 86 in |
| Width Over Tracks | 89 in |
| Length w/ Blade | 156 in |
| Length w/o Blade | 120 in |
Transmission
| Transmission Type | HS |
|---|---|
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Track Gauge | 66 in |
|---|---|
| Number of Track Rollers per Side | 6 |
| Number of Shoes per Side | 41 |
| Number of Carrier Rollers per Side | 1 |
| Standard Shoe Size | 24 in |
| Track Pitch | 6 in |
Standard Blade
| Width | 114 in |
|---|---|
| Height | 35 in |
