Komatsu
Dressta
TD-7M
Crawler Dozer
36 specifications
:quality(50)/61022/b5f2b0c4-f2be-4a9e-b7d9-a3e1fe1200a2.png)
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 26,985 lb |
|---|
Engine
| Engine Model | 6D125-1 |
|---|---|
| Displacement | 674 in³ |
| Power Measured @ | 1,750 rpm |
| Gross Power | 124.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 115 in |
| Length of Track on Ground | 88 in |
| Width Over Tracks | 93 in |
| Length w/ Blade | 189 in |
Transmission
| Transmission Type | DD |
|---|---|
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 4 |
Undercarriage
| Track Gauge | 74 in |
|---|---|
| Number of Track Rollers per Side | 5 |
| Number of Shoes per Side | 39 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 18 in |
| Track Pitch | 7 in |
Standard Blade
| Width | 148 in |
|---|---|
| Height | 35 in |
