Komatsu
Liebherr
LR614
Crawler Loader
36 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 39,022 lb |
|---|---|
| Bucket Capacity - heaped | 2.39 yd³ |
| Max Speed | 7.1 mph |
| Fuel Capacity | 74.0 gal |
| Static Tipping Load | 23,810 lb |
| Breakout Force Bucket | 29,320 lb |
| Cooling System Fluid Capacity | 14.6 gal |
Engine
| Engine Model | NH220-CI |
|---|---|
| Displacement | 743 in³ |
| Net Power | 155.0 hp |
Dimensions
| Height - Top of Cab | 119 in |
|---|---|
| Width to Outside of Tracks | 94 in |
| Length with Bucket on Ground | 228 in |
| Reach at Dump Height | 52 in |
| Clearance at Full Height and Dump | 108 in |
Undercarriage
| Length of Track on Ground | 104 in |
|---|---|
| Track Gauge | 74 in |
| Track Shoe Width | 18 in |
| Ground Pressure | 10 psi |
| Number of Track Rollers per Side | 6 |
