Komatsu
D61EX-15E0
- Operating Weight
- 36,839 lb
- Max Speed - Forward
- 5.4 mph
- Gross Power
- 170.0 hp
- Net Power
- 168.0 hp
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 36,839 lb |
|---|---|
| Fuel Capacity | 103.1 gal |
| Cooling System Fluid Capacity | 8.5 gal |
| Final Drives Fluid Capacity | 7.6 gal |
| Engine Oil Capacity | 7.7 gal |
Engine
| Engine Model | SAA6D107E-1 |
|---|---|
| Displacement | 408 in³ |
| Power Measured @ | 1,850 rpm |
| Gross Power | 170.0 hp |
| Net Power | 168.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 125 in |
| Length of Track on Ground | 199 in |
| Width Over Tracks | 130 in |
Transmission
| Max Speed - Forward | 5.4 mph |
|---|---|
| Max Speed - Reverse | 6.8 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 76 in |
| Number of Track Rollers per Side | 7 |
| Number of Shoes per Side | 40 |
| Standard Shoe Size | 24 in |
| Ground Contact Area | 4,836 in³ |
