Komatsu

D61P-12

Crawler Dozer

Operating Weight
37,258 lb
Gross Power
150.0 hp
All crawler dozers
Komatsu D61P-12 Crawler Dozer
1 / 5
Image 1 of 5
Image: hrparts.com

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight37,258 lb

Engine

Engine specifications
Engine ModelS6D114E-1A
Displacement505 in³
Power Measured @1,850 rpm
Gross Power150.0 hp
Number of Cylinders6

Dimensions

Dimensions specifications
Ground Clearance19 in
Height - Top of Cab121 in
Length of Track on Ground126 in
Width Over Tracks119 in
Length w/ Blade216 in

Transmission

Transmission specifications
Transmission TypeTF
Number of Forward Gears3
Number of Reverse Gears3

Undercarriage

Undercarriage specifications
Track Gauge85 in
Number of Track Rollers per Side8
Number of Carrier Rollers per Side2
Standard Shoe Size34 in
Track Pitch8 in

Standard Blade

Standard Blade specifications
Width152 in
Height46 in
