Komatsu
New Holland
D150
Crawler Dozer
40 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 36,454 lb |
|---|---|
| Fuel Capacity | 107.3 gal |
| Cooling System Fluid Capacity | 13.8 gal |
| Final Drives Fluid Capacity | 6.4 gal |
| Engine Oil Capacity | 10.1 gal |
| Hydraulic Fluid Capacity | 14.6 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | S6D125E-2 |
|---|---|
| Displacement | 674 in³ |
| Net Power | 190.5 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Max Torque | 724 lb-ft |
Hydraulic System
| Pump Flow Capacity | 55.5 gal/min |
|---|---|
| Relief Valve Pressure | 2,988 psi |
| Pump Type | Double acting piston |
Dimensions
| Height - Top of Cab | 125 in |
|---|---|
| Length of Track on Ground | 106 in |
| Length w/ Blade | 215 in |
Transmission
| Max Speed - Forward | 3.9 mph |
|---|---|
| Max Speed - Reverse | 5.0 mph |
| Transmission Type | Torqueflow Transmission planetary gear |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 74 in |
| Number of Track Rollers per Side | 2 |
| Number of Shoes per Side | 39 |
| Standard Shoe Size | 24 in |
| Ground Contact Area | 5,059 in³ |
Standard Blade
| Width | 137 in |
|---|---|
| Height | 56 in |
| Capacity | 7.40 yd³ |
