KomatsuKomatsu
D87E-3
Crawler Dozer
41 specifications
Komatsu
D65WX-17
- Operating Weight
- 45,945 lb
- Max Speed - Forward
- 5.3 mph
- Gross Power
- 207.0 hp
- Net Power
- 205.0 hp
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 45,945 lb |
|---|---|
| Fuel Capacity | 109.6 gal |
| Cooling System Fluid Capacity | 14.3 gal |
| Final Drives Fluid Capacity | 4.4 gal |
| Engine Oil Capacity | 6.6 gal |
| Hydraulic Fluid Capacity | 12.7 gal |
Engine
| Engine Model | SAA6D114E-5 |
|---|---|
| Displacement | 9 in³ |
| Power Measured @ | 1,950 rpm |
| Gross Power | 207.0 hp |
| Net Power | 205.0 hp |
| Number of Cylinders | 6 |
| Make | Komatsu |
Hydraulic System
| Pump Flow Capacity | 14.5 gal/min |
|---|---|
| Relief Valve Pressure | 4,050 psi |
| Pump Type | Piston |
Transmission
| Max Speed - Forward | 5.3 mph |
|---|---|
| Max Speed - Reverse | 8.3 mph |
| Transmission Type | TORQFLOW |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
