Komatsu
New Holland
D150
Crawler Dozer
40 specifications
Komatsu
DP61PX-15EO
- Operating Weight
- 34,440 lb
- Max Speed - Forward
- 5.4 mph
- Gross Power
- 170.0 hp
- Net Power
- 168.0 hp
:quality(50)/103848/4454cfb9-241b-40be-b5a3-ee2ced9273b8.webp)
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 34,440 lb |
|---|---|
| Fuel Capacity | 103.0 gal |
| Cooling System Fluid Capacity | 8.5 gal |
| Final Drives Fluid Capacity | 7.5 gal |
| Engine Oil Capacity | 7.7 gal |
| Hydraulic Fluid Capacity | 0.3 gal |
Engine
| Engine Model | SAA6D107E-1 |
|---|---|
| Displacement | 7 in³ |
| Power Measured @ | 1,850 rpm |
| Gross Power | 170.0 hp |
| Net Power | 168.0 hp |
| Number of Cylinders | 6 |
Hydraulic System
| Pump Flow Capacity | 14.5 gal/min |
|---|---|
| Relief Valve Pressure | 2,990 psi |
| Pump Type | Plunger-type |
Transmission
| Max Speed - Forward | 5.4 mph |
|---|---|
| Max Speed - Reverse | 5.4 mph |
| Transmission Type | TORQFLOW |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 84 in |
| Number of Track Rollers per Side | 8 |
| Number of Shoes per Side | 46 |
| Standard Shoe Size | 34 in |
| Ground Contact Area | 8,451 in³ |
| Track Pitch | 11 in |
