KomatsuKomatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 9,502 lb |
|---|---|
| Max Speed | 11.9 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
Engine
| Engine Model | 4D94LE |
|---|---|
| Displacement | 187 in³ |
| Power Measured @ | 2,450 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,800 rpm |
| Engine Make | Yanmar |
| Power | 65.0 hp |
| Fuel Type | Diesel |
| Torque | 141 lb-ft |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Wheelbase | 67 in |
| Overall Width | 49 in |
| Turning Radius | 94 in |
| Overall Height - mast lowered | 85 in |
| Length to Fork Face | 107 in |
| Height to Top of Overhead Guard | 84 in |
| Max Fork Height | 128 in |
| Right Angle Stack | 113 in |
Mast
| Load Capacity | 6,001 lb |
|---|---|
| Load Center | 19 in |
| Lift Speed | 1.2 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 12 ° |
| Lower Speed | 1.1 mph |
