Komatsu
Hyundai
HBR14-7
Forklift
19 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 7,941 lb |
|---|---|
| Max Speed | 11.2 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
| Fuel Capacity | 15.3 gal |
Engine
| Engine Model | K21 |
|---|---|
| Displacement | 126 in³ |
| Power Measured @ | 2,700 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,600 rpm |
| Engine Make | GCT |
| Power | 56.0 hp |
| Fuel Type | LPG |
| Torque | 119 lb-ft |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Wheelbase | 66 in |
| Overall Width | 46 in |
| Turning Radius | 89 in |
| Overall Height - mast lowered | 86 in |
| Length to Fork Face | 103 in |
| Height to Top of Overhead Guard | 84 in |
| Max Fork Height | 128 in |
| Right Angle Stack | 107 in |
Mast
| Load Capacity | 5,000 lb |
|---|---|
| Load Center | 18 in |
| Lift Speed | 1.4 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 12 ° |
| Lower Speed | 1.1 mph |
