KomatsuKomatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 9,436 lb |
|---|---|
| Max Speed | 10.6 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Cushion |
| Fuel Capacity | 10.2 gal |
Engine
| Engine Model | K25 |
|---|---|
| Displacement | 152 in³ |
| Power Measured @ | 2,700 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,600 rpm |
| Engine Make | Nissan |
| Power | 60.0 hp |
| Fuel Type | LPG |
| Torque | 142 lb-ft |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Wheelbase | 57 in |
| Overall Width | 44 in |
| Turning Radius | 81 in |
| Overall Height - mast lowered | 88 in |
| Length to Fork Face | 96 in |
| Height to Top of Overhead Guard | 81 in |
| Max Fork Height | 128 in |
| Right Angle Stack | 100 in |
Mast
| Load Capacity | 6,001 lb |
|---|---|
| Load Center | 17 in |
| Lift Speed | 1.2 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 8 ° |
| Lower Speed | 1.1 mph |
