Komatsu
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Fuel Capacity | 66.1 gal |
|---|---|
| Tire Size | 20.5-25 |
Engine
| Engine Model | S6D125 |
|---|---|
| Displacement | 671 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 248.1 hp |
| Net Power | 240.0 hp |
| Number of Cylinders | 6 |
Weights
| Total Empty | 37,038 lb |
|---|---|
| Front Axle - empty | 18,629 lb |
| Total Loaded | 92,153 lb |
| Rear Axle - empty | 18,409 lb |
| Front Axle - loaded | 31,085 lb |
| Rear Axle - loaded | 61,068 lb |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 158 in |
| Overall Length | 367 in |
| Overall Width | 100 in |
| Overall Height | 132 in |
| Dump Height | 239 in |
Transmission
| Max Speed | 29.9 mph |
|---|---|
| Number of Forward Gears | 6 |
Dump
| Rated Payload | 55,116 lb |
|---|---|
| Capacity - Heaped | 18.80 yd³ |
