Komatsu
JCB
714
Off-Highway Truck
43 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Tire Size | front 14.00-25-20PR rear 16.00-25-24PR |
|---|---|
| Alternator Supplied Amperage | — |
Engine
| Engine Model | Cummins NTO-6-B |
|---|---|
| Displacement | 743 in³ |
| Gross Power | 230.0 hp |
Weights
| Empty Weight | 37,016 lb |
|---|---|
| Loaded Weight | 76,941 lb |
| Weight Distribution Front - loaded | 25.0 % |
| Weight Distribution Rear - loaded | 75.0 % |
| Weight Distribution Front - empty | 42.1 % |
| Weight Distribution Rear - empty | 57.9 % |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 158 in |
| Overall Length | 288 in |
| Overall Width | 119 in |
| Overall Height | 131 in |
| Dump Height | 241 in |
| Dump Ground Clearance | 19 in |
Transmission
| Max Speed | 32.4 mph |
|---|---|
| Transmission Type | constant mesh |
| Number of Gears - Forward | 7 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 35,996.1 gal |
|---|
Dump
| Dump Angle | 65 ° |
|---|---|
| Raise Time | 8.0 s |
| Load Capacity - heaped | 18.60 yd³ |
| Load Capacity - Struck | 14.00 yd³ |
