Komatsu
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Fuel Capacity | 132.1 gal |
|---|---|
| Tire Size | 18.00-25-32 |
| Engine Oil Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 35.2 gal |
| Hydraulic System Fluid Capacity | 29.1 gal |
| Alternator Supplied Amperage | — |
| Diff and Final Drive Fluid Capacity | 18.8 gal |
Engine
| Engine Model | NTA855 |
|---|---|
| Displacement | 855 in³ |
| Gross Power | 405.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | — |
| Rated Engine Speed | 29 rpm |
Weights
| Empty Weight | 56,769 lb |
|---|---|
| Loaded Weight | 127,317 lb |
| Weight Distribution Front - loaded | 32.0 % |
| Weight Distribution Rear - loaded | 68.0 % |
| Weight Distribution Front - empty | 48.0 % |
| Weight Distribution Rear - empty | 52.0 % |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Wheelbase | 149 in |
| Overall Length | 301 in |
| Overall Width | 145 in |
| Overall Height | 152 in |
| Dump Height | 296 in |
| Dump Ground Clearance | 18 in |
Transmission
| Max Speed | 38.6 mph |
|---|---|
| Transmission Type | Komatsu TORQFLOW planetary gear |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 63,993.0 gal |
|---|
Dump
| Dump Angle | 61 ° |
|---|---|
| Load Capacity - heaped | 31.40 yd³ |
