KomatsuEuclid
R85B
Off-Highway Truck
39 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Fuel Capacity | 206.1 gal |
|---|---|
| Engine Oil Capacity | 21.1 gal |
| Hydraulic System Fluid Capacity | 32.2 gal |
| Alternator Supplied Amperage | — |
| Diff and Final Drive Fluid Capacity | 36.2 gal |
Engine
| Engine Model | SAA6D170E-5 |
|---|---|
| Displacement | 1,413 in³ |
| Gross Power | 739.0 hp |
| Net Power | 715.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbo-charged |
| Torque Measured @ | — |
| Make | Komatsu |
| Rated Engine Speed | 32 rpm |
Weights
| Operating Weight | 219,760 lb |
|---|---|
| Empty Weight | 95,020 lb |
| Loaded Weight | 219,760 lb |
| Weight Distribution Front - loaded | 32.0 % |
| Weight Distribution Rear - loaded | 68.0 % |
| Weight Distribution Front - empty | 47.0 % |
| Weight Distribution Rear - empty | 53.0 % |
Dimensions
| Wheelbase | 169 in |
|---|---|
| Overall Length | 369 in |
| Overall Width | 168 in |
| Overall Height | 174 in |
| Dump Height | 347 in |
| Dump Ground Clearance | 23 in |
Transmission
| Max Speed | 43.5 mph |
|---|---|
| Transmission Type | Full-automatic planetary type |
| Number of Gears - Forward | 7 |
| Number of Gears - Reverse | 1 |
Drive System
| Drive Config | rwd |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 121,986.7 gal |
|---|
Articulating/Rigid
| Articulating/Rigid | Rigid |
|---|
Dump
| Dump Angle | 48 ° |
|---|---|
| Load Capacity - heaped | 44.69 yd³ |
| Load Capacity - Struck | 32.70 yd³ |
