Komatsu
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Fuel Capacity | 264.2 gal |
|---|---|
| Tire Size | 24.00-49-42PR |
| Engine Oil Capacity | 23.8 gal |
| Cooling System Fluid Capacity | 60.8 gal |
| Alternator Supplied Amperage | — |
Engine
| Engine Model | VTA-1710 |
|---|---|
| Displacement | 1,709 in³ |
| Gross Power | 800.0 hp |
| Net Power | 782.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | — |
Dimensions
| Ground Clearance | 31 in |
|---|---|
| Wheelbase | 187 in |
| Overall Length | 394 in |
| Overall Width | 226 in |
| Overall Height | 192 in |
| Dump Height | 355 in |
| Dump Ground Clearance | 36 in |
Transmission
| Max Speed | 40.4 mph |
|---|---|
| Transmission Type | TORQFLOW planetary gear |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 1 |
Dump
| Rated Payload | — |
|---|---|
| Dump Angle | 64 ° |
