Komatsu
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Fuel Capacity | 101.0 gal |
|---|---|
| Tire Size | 23.5R25 |
| Engine Oil Capacity | 9.3 gal |
| Hydraulic System Fluid Capacity | 31.8 gal |
| Transmission Fluid Capacity | 20.5 gal |
Engine
| Engine Model | SAA6D125E-3 |
|---|---|
| Displacement | 674 in³ |
| Gross Power | 335.3 hp |
| Net Power | 324.6 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Max Torque | 1,180 lb-ft |
Weights
| Total Empty | 49,604 lb |
|---|---|
| Front Axle - empty | 28,175 lb |
| Total Loaded | 109,956 lb |
| Rear Axle - empty | 10,417 lb |
| Front Axle - loaded | 32,767 lb |
| Rear Axle - loaded | 37,935 lb |
| Center Axle - empty | 11,012 lb |
| Center Axle - loaded | 39,254 lb |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Wheelbase | 196 in |
| Overall Length | 398 in |
| Overall Height | 138 in |
| Dump Height | 254 in |
| Dump Ground Clearance | 24 in |
Transmission
| Max Speed | 36.7 mph |
|---|---|
| Transmission Type | full-automatic |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 2 |
Dump
| Rated Payload | 60,186 lb |
|---|---|
| Dump Angle | 70 ° |
| Raise Time | 12.0 s |
| Capacity - Heaped | 21.80 yd³ |
| Capacity - Struck | 16.90 yd³ |
