Komatsu
John Deere
460E
Off-Highway Truck
31 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Fuel Capacity | 102.5 gal |
|---|---|
| Tire Size | 23.5 R25 |
| Engine Oil Capacity | 9.3 gal |
| Hydraulic System Fluid Capacity | 27.3 gal |
| Transmission Fluid Capacity | 25.9 gal |
Engine
| Engine Model | SAA6D125E-7 |
|---|---|
| Displacement | 674 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 332.6 hp |
| Net Power | 324.6 hp |
| Number of Cylinders | 6 |
| Max Torque | 1 lb-ft |
| Make | Komatsu |
| Stroke | 6 in |
| Bore | 5 in |
Weights
| Operating Weight | 117,881 lb |
|---|---|
| Total Empty | 56 lb |
| Total Loaded | 118 lb |
| Rear Axle - empty | 18 lb |
| Front Axle - loaded | 31 lb |
| Rear Axle - loaded | 33 lb |
| Center Axle - empty | 23 lb |
| Center Axle - loaded | 36 lb |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Wheelbase | 162 in |
| Overall Length | 406 in |
| Overall Width | 115 in |
| Overall Height | 143 in |
| Dump Height | 254 in |
| Dump Ground Clearance | 24 in |
Transmission
| Max Speed | 36.5 mph |
|---|---|
| Transmission Type | Full-automatic Counter-shaft type |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
General Specifications
| Operating Weight lbs (kg) | 117,892 (53,475) Starting 2019 Model Year |
|---|---|
| Engine type | Komatsu SAA6D125E-7 Starting 2019 Model Year |
| Articulated/Rigid | Articulated Starting 2024 Model Year |
| Drive Configuration | 6WD Starting 2019 Model Year |
| Rated Payload Tons (Metric Tons) | 30.9+E6 (28) Starting 2021 Model Year |
| Mfg. Model | HM300-5 Starting 2019 Model Year |
| Drive System Mech/Electr. | Mech Starting 2025 Model Year |
| Off-Highway Trucks | Off-Highway Trucks Starting 2025 Model Year |
Drive System
| Drive Config | 6WD |
|---|
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 56,000 lb |
|---|---|
| Capacity - Heaped | 22.41 yd³ |
| Capacity - Struck | 17.61 yd³ |
