Terex
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Fuel Capacity | 98.0 gal |
|---|---|
| Tire Size | 21.00 x 35-28PR |
| Alternator Supplied Amperage | — |
Engine
| Engine Model | DD 12V-71T |
|---|---|
| Net Power | 321.0 hp |
Weights
| Empty Weight | 71,600 lb |
|---|---|
| Loaded Weight | 151,600 lb |
Dimensions
| Wheelbase | 156 in |
|---|---|
| Overall Length | 331 in |
| Overall Width | 161 in |
| Overall Height | 172 in |
Transmission
| Max Speed | 66.0 mph |
|---|---|
| Transmission Type | Allison CLBT-5960 |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 80,019.1 gal |
|---|
Dump
| Rated Payload | 80,028 lb |
|---|---|
| Load Capacity - heaped | 31.99 yd³ |
| Load Capacity - Struck | 25.40 yd³ |
