Komatsu
Case
CX75 SR
Excavator
50 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 27,690 lb |
|---|---|
| Fuel Capacity | 65.3 gal |
| Hydraulic Pump Flow Capacity | 64.0 gal/min |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Hydraulic System Relief Valve Pressure | 5,050 psi |
| Engine Oil Capacity | 3.1 gal |
| Cooling System Fluid Capacity | 3.7 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 0.7 gal |
| Alternator Supplied Amperage | 35 A |
Engine
| Engine Model | SAA4D95LE-5 |
|---|---|
| Displacement | 199 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 96.6 hp |
| Net Power | 91.2 hp |
| Aspiration | Turbocharged air-to-air aftercooled |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 113 in |
| Length of Track on Ground | 114 in |
| Tail Swing Radius | 86 in |
| Width to Outside of Tracks | 102 in |
| Removal Counterweight Clearance | 36 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 79 in |
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 43 |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 27,651 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 219 in |
|---|---|
| Max Reach Along Ground | 323 in |
| Max Loading Height | 245 in |
| Max Vertical Wall Digging Depth | 197 in |
| Max Cutting Height | 341 in |
| Shipping Length of Unit | 300 in |
| Shipping Height of Unit | 114 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.80 yd³ |
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
