Komatsu

PC340-6

Excavator

Operating Weight
71,606 lb
Max Digging Depth
251 in
Max Digging Depth
265 in
Net Power
232.0 hp
All excavators
Komatsu PC340-6 Excavator
1 / 5
Image 1 of 5
Image: taopparts.com

Specifications

49 data points

Operating Specifications

Operating Specifications specifications
Operating Weight71,606 lb
Fuel Capacity142.7 gal
Hydraulic Pump Flow Capacity132.1 gal/min
Hydraulic System Fluid Capacity54.2 gal
Hydraulic System Relief Valve Pressure5,050 psi

Engine

Engine specifications
Engine ModelSA6D114E
Displacement505 in³
Power Measured @1,750 rpm
Net Power232.0 hp

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab124 in
Length of Track on Ground146 in
Tail Swing Radius131 in
Width to Outside of Tracks126 in
Removal Counterweight Clearance47 in

Undercarriage

Undercarriage specifications
Ground Pressure10 psi
Track Gauge102 in
Max Travel Speed3.5 mph
Shoe Size24 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth251 in
Max Reach Along Ground393 in
Max Loading Height261 in
Max Vertical Wall Digging Depth202 in
Max Cutting Height378 in
Shipping Length of Unit438 in
Shipping Height of Unit139 in

Bucket

Bucket specifications
Reference Bucket Capacity1.80 yd³
Maximum Bucket Capacity2.39 yd³
Minimum Bucket Capacity0.71 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth265 in
Max Vertical Wall Digging Depth230 in
Max Cutting Height394 in
Max Loading Height272 in
Max Reach Along Ground408 in
Shipping Length of Unit433 in
Shipping Height of Unit134 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth292 in
Max Cutting Height402 in
Max Loading Height281 in
Max Vertical Wall Digging Depth256 in
Max Reach Along Ground431 in
Shipping Length of Unit431 in

Boom/Stick Excavator Option 4

Boom/Stick Excavator Option 4 specifications
Max Digging Depth323 in
Max Cutting Height417 in
Max Reach Along Ground462 in
Max Loading Height296 in
Max Vertical Wall Dig Depth287 in
Shipping Length of Unit432 in
