Komatsu
Volvo
EC210B LC
Excavator
26 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 78,255 lb |
|---|---|
| Fuel Capacity | 159.9 gal |
| Hydraulic Pump Flow Capacity | 141.3 gal/min |
| Hydraulic System Fluid Capacity | 49.7 gal |
| Hydraulic System Relief Valve Pressure | 5,400 psi |
Engine
| Engine Model | SAA6D114E-5 |
|---|---|
| Displacement | 540 in³ |
| Power Measured @ | 1,950 rpm |
| Net Power | 271.0 hp |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 125 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 137 in |
| Width to Outside of Tracks | 135 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 102 in |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 34 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 292 in |
|---|---|
| Max Reach Along Ground | 431 in |
| Max Vertical Wall Digging Depth | 256 in |
Bucket
| Reference Bucket Capacity | 1.80 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
