Volvo
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 47,000 lb |
|---|---|
| Fuel Capacity | 124.2 gal |
| Hydraulic System Fluid Capacity | 105.7 gal |
| Engine Oil Capacity | 8.5 gal |
| Cooling System Fluid Capacity | 10.9 gal |
Engine
| Engine Model | D7 |
|---|---|
| Displacement | 433 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 188.0 hp |
| Net Power | 181.0 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 120 in |
| Length of Track on Ground | 183 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 46 in |
Undercarriage
| Number of Track Rollers per Side | 2 |
|---|---|
| Max Travel Speed | 3.5 mph |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 9 |
| Drawbar Pull | 48,784 lb |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
