Mini Excavator
34 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight | 10,472 lb |
|---|---|
| Fuel Capacity | 13.7 gal |
| Hydraulic Pump Flow Capacity | 34.3 gal/min |
| Hydraulic System Fluid Capacity | 8.8 gal |
| Hydraulic System Relief Valve Pressure | 3,626 psi |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Capacity | 2.2 gal |
| Cooling System Fluid Capacity | 2.0 gal |
Engine
| Engine Model | 4D84E-3FA |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 44.1 hp |
| Net Power | 38.8 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
| Torque Measured @ | 1,800 rpm |
| Max Torque | 87 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 101 in |
| Tail Swing Radius | 59 in |
| Width to Outside of Tracks | 76 in |
| Removal Counterweight Clearance | 25 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 60 in |
| Number of Track Rollers per Side | 5 |
| Max Travel Speed | 2.9 mph |
| Shoe Size | 16 in |
| Number of Shoes per Side | 38 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 139 in |
|---|---|
| Max Reach Along Ground | 229 in |
| Max Vertical Wall Digging Depth | 103 in |
| Max Loading Height | 166 in |
| Shipping Length of Unit | 216 in |
| Max Cutting Height | 227 in |
| Shipping Height of Unit | 101 in |
Bucket
| Reference Bucket Capacity | 0.30 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.30 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 154 in |
|---|---|
| Max Cutting Height | 235 in |
| Max Loading Height | 174 in |
| Max Vertical Wall Digging Depth | 113 in |
| Max Reach Along Ground | 244 in |
| Shipping Height of Unit | 101 in |
| Shipping Length of Unit | 216 in |
