John Deere
Hitachi
ZX17U-5
Mini Excavator
30 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 6,300 lb |
|---|---|
| Fuel Capacity | 11.4 gal |
| Hydraulic Pump Flow Capacity | 9.0 gal/min |
| Hydraulic System Fluid Capacity | 22.5 gal |
| Hydraulic System Relief Valve Pressure | 2,130 psi |
| Operating Voltage | 12 V |
| Engine Oil Capacity | 1.1 gal |
| Cooling System Fluid Capacity | 1.5 gal |
| Swing Drive Fluid Capacity | 0.7 gal |
Engine
| Engine Model | 3TN82-RJB |
|---|---|
| Displacement | 83 in³ |
| Power Measured @ | 2,350 rpm |
| Net Power | 24.0 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 65 lb-ft |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 95 in |
| Tail Swing Radius | 54 in |
| Width to Outside of Tracks | 61 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 48 in |
| Number of Track Rollers per Side | 1 |
| Max Travel Speed | 1.3 mph |
| Shoe Size | 13 in |
| Number of Shoes per Side | 40 |
| Number of Carrier Rollers per Side | 4 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 104 in |
|---|---|
| Max Reach Along Ground | 179 in |
| Max Loading Height | 111 in |
| Shipping Length of Unit | 183 in |
| Shipping Height of Unit | 95 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
