Komatsu

PC650LC-8

Excavator

Operating Weight
146,390 lb
Max Digging Depth
333 in
Net Power
429.0 hp
All excavators
Komatsu PC650LC-8 Excavator
1 / 5
Image 1 of 5
Image: kirby-smith.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight146,390 lb
Fuel Capacity232.5 gal
Hydraulic System Fluid Capacity95.0 gal
Engine Oil Capacity10.6 gal
Cooling System Fluid Capacity15.3 gal
Swing Drive Fluid Capacity6.8 gal

Engine

Engine specifications
Engine ModelSAA6D140E-5
Power Measured @1,800 rpm
Net Power429.0 hp

Dimensions

Dimensions specifications
Ground Clearance31 in
Height - Top of Cab130 in
Length of Track on Ground224 in
Tail Swing Radius156 in
Width to Outside of Tracks138 in

Undercarriage

Undercarriage specifications
Number of Track Rollers per Side9
Max Travel Speed3.0 mph
Number of Shoes per Side52
Number of Carrier Rollers per Side3
Drawbar Pull93,250 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth333 in
Max Reach Along Ground504 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed8 rpm
